YRKS Series Water-Air Cooled High Voltage 6KV 10KV Wound Rotor Slip Ring Motor

YRKS-series (3kv, 6kv,10kV) motor, is of wound-water-cooled three-phase asynchronous motor. Which complies with JB/T7594-1994 and JB/T10314.1-2002. The power class, installation dimensions and electrical performance of this type of motor are in compliance with relevant IEC standards. The motor has such advantage as high efficiency, energy-saving low noise, low vibration, light weight and reliable performance. They are easy for installation and maintenance.

YRKS large water cooler motor addition set, bearing temperature measuring device, can also add heating device inside the motor, the shaft extension of the motor uses the tangential key, the motor carbon brush is not lifting structure, the front and rear bearing chambers of the motor have Oil filling and oil draining device.

This motor can generate larger starting torque at the state of relatively lower starting current. It used where the capacity of the feeder line is insufficient to start a squirrel cage motor or where the longer starting time and frequent starting are needed or where adjustment of speed is needed within a limited range such as windlass, press machines, drawing machines.

YRKS Series Water-Air Cooled High Voltage 6KV 10KV Wound Rotor Slip Ring Motor Model Significance

YRKS Series Water-Air Cooled High Voltage 6KV 10KV Wound Rotor Slip Ring Motor Product Parameters

Center height range: H355 – 1000mm
Power range: 220kW ~ 5600kW
Number of poles: 4/6/8/10/12
Rated voltage: 30000V/6000V/6600V/10000V/11000V, other voltage requirement or special requirements should be negotiate with manufacturer before order is placed.
Speed: 500RPM/590RPM/740RPM/990RPM/1500RPM/3000RPM
Rated frequency: 50HZ/60HZ
Protection level: IP44 or IP54
Insulation class: F
Work system: S1 (continuous)
Cooling method: IC81W
Installation form: IMB3
Package: Export Wooden Package
Motor connection: Y (three outlet terminals in the junction box, the junction box from the extension of the spindle is located on the right side of the base)
Altitude: no more than 1000m
This type of motor is suitable for use in environments where the ambient air temperature does not exceed 40 ° C and there is no serious dust, the minimum ambient air temperature is -15 ° C, and there is no corrosive and explosive gas in the air (which can also be made into a damp heat or high-altitude motor).

Comparison of Different Deries High Voltage Motor
