Y2 Cast Iron Housing Three Phase Electric Motor

Y2 Series motor is totally enclosed and fan cooling, three-phase squirrel cage induction motor. Y2 series Three Phase Asynchronous Induction Electric motors are newly designed by our company for European and American market on the basis of Y2 series. It is newly deigned in conformity with the relevant rules of IEC and DIN42673 standards. The motors are conformity with IEC60034-1 and JB/T8680-2008 standards, also up to the international advanced level of 90’s, it possess sophisticated features such as new construction, good appearance, slight vibration, low noise etc. Its rated power, mounting size are same as Y2 series. The efficiency of the Motor meets EFF2, EFF1.

Y2 Three-Phase Cast Iron Housing Three Phase Electric Motor Application

Y2 series motors are widely used in many places, where do not exist combustible, explosive or corrosive gas, without any special requirements, such as machine tools, pumps, fans, transport machinery, mixer, agriculture machinery and food machines etc.

Y2 Three-Phase Cast Iron Housing Three Phase Electric Motor Operating Conditions

Complete Y2 Series ranges from 0.12 Kw to 315 Kw.Sizes other than listed are available on request
Rated voltage: 380V or any voltage between 220V-760V.
Rated frequency: 50HZ, 60HZ
Protection Class: IP44, IP54 ,IP55
Insulation Class: B, F, H
Cooling method: ICO141
Duty: S1 (continuous)
Connection: Star connection for up to 3kw, delta connection for 4kw and above.
Ambient temperature: -15°C≤θ≤40°C
Altitude: not exceed 1000m
Bearing: Chinese good bearings, or SKF,NSK if request
Remarks: Motors can be equipped with PTC, for frame size 160 and above also can be equipped with re-greasing system. Terminal box on top , right and left are available. Key way can be closed type or opened type. Right side or left are available.

Y2 Three-Phase Cast Iron Housing Three Phase Electric Motor Manufacturer

Bulletproof electric motor specializing in various series from low voltage (like three phase Y, Y2, YR, YE2, YE3, JR, YS, MS, YEJ, YCT and YZR series and single phase YL, YC, YY, ML, MC, MY and YB3 explosion proof motors) to high voltage (like Y, R, YKK, YRKK and YKS series) electric motors with high efficiency and energy saving, economization on power and material consumption. Besides, we also do OEM to meet their diversified and personalized needs. As a national key project, Bulletproof is committed to the quality of the products and service to satisfy the customers’ demands. We also achieve the ISO9001 certificate and SABS certificate. Meanwhile, the products win favor of overseas customers. Welcome to visit our manufacturer, welcome to the Motor World!
